CW-PCS03: 2″ Bell Cable Spacers for Lashing Support

Height 2″ cable Spacers are used to separate cable from messenger. UV-stabilized polyethylene spacers and stainless steel straps.

CW-PCS03: 2″ Bell Cable Spacers for Lashing Support

Height 2″ cable Spacers are used to separate cable from messenger. UV-stabilized polyethylene spacers and stainless steel straps.

Description

Used in lashed cable construction to provide a separation between the cable and strand.

A slot is provided to guide and secure lashed cable supports.

Molded from polyvinyl chloride (PVC).

Height: 2″

Type: Bell Type



Installation:
install bell cable spacers

  1. Measure the diameter or circumference of the bundle. Use the table to determine strap length.
  2. Thread strap through spacer slot.
  3. Wrap the strap around the bundle (strand, spacer, cables) then through the buckle twice, pulling each wrap tight.
  4. Strap end should be doubled under itself (about 1.5″) before making a final pass through the buckle. Trim off excess.
  5. Bend doubled thickness over the top of the buckle to prevent unraveling.



Note: In cable installation, straps should not be too tight as they may restrict cable movement during contraction and expansion and possibly damage the cable.

Parts No. Description Material Height
CW-PCS03 2″ Bell Cable Spacers for Lashing Support Polyethylene 2″

Description

Used in lashed cable construction to provide a separation between the cable and strand.

A slot is provided to guide and secure lashed cable supports.

Molded from polyvinyl chloride (PVC).

Height: 2″

Type: Bell Type



Installation:
install bell cable spacers

  1. Measure the diameter or circumference of the bundle. Use the table to determine strap length.
  2. Thread strap through spacer slot.
  3. Wrap the strap around the bundle (strand, spacer, cables) then through the buckle twice, pulling each wrap tight.
  4. Strap end should be doubled under itself (about 1.5″) before making a final pass through the buckle. Trim off excess.
  5. Bend doubled thickness over the top of the buckle to prevent unraveling.



Note: In cable installation, straps should not be too tight as they may restrict cable movement during contraction and expansion and possibly damage the cable.

Parts No. Description Material Height
CW-PCS03 2″ Bell Cable Spacers for Lashing Support Polyethylene 2″
