CW-MS Mast Strap for Drop Wire Clamp Attachment

Use the CW-MS mast strap to attach compatible drop wire clamp bails to your steel mast. The listed mast range is 1¼–2 inches, and the hot-dip galvanized assembly includes bolts, nuts and washers.

Confirm the actual mast dimensions, hook-to-bail fit and intended drop arrangement before ordering. Hbcrownwealth supports wholesale supply and OEM/ODM review.

CW-MS Mast Strap for Drop Wire Clamp Attachment

Use the CW-MS mast strap to attach compatible drop wire clamp bails to your steel mast. The listed mast range is 1¼–2 inches, and the hot-dip galvanized assembly includes bolts, nuts and washers.

Confirm the actual mast dimensions, hook-to-bail fit and intended drop arrangement before ordering. Hbcrownwealth supports wholesale supply and OEM/ODM review.

CW-MS Mast Strap for Steel Mast Drop Connections

The CW-MS mast strap wraps around a steel mast to provide an attachment for the bail of a compatible drop wire clamp. Its listed mast range is 1¼–2 inches. The assembly includes bolts, nuts and washers and uses a hot-dip galvanized finish.

You can use the drop wire hook for multiple connections when the clamp arrangement and required loads permit. Select the strap by your mast dimensions, then check the bail-to-hook fit. Your chosen drop wire clamp determines cable compatibility.

Product Specifications

Model CW-MS
Product Mast strap for drop wire clamp attachment
Strap material AISI 1008 steel, as listed in the parameter table
Surface finish Hot-dip galvanized
Listed mast range 1¼–2 in
Mounting structure Steel mast
Included hardware Bolts, nuts and washers; described as Grade 2 steel in the original specification
Attachment Hook accepting the bail of a compatible drop wire clamp
Drop arrangement Multiple drops, subject to confirmed fit and assembly loads

Provide the actual mast outside diameter and pipe designation when ordering. Confirm fit against the supply drawing; nominal pipe size and outside diameter can differ.

Advantages for Your Mast Assembly

  • Defined mast range: The listed 1¼–2 inch size gives you a starting point for checking the strap against your steel mast.
  • Included fixing components: Bolts, nuts and washers form part of the stated supply. Confirm their dimensions and quantities in your order.
  • Clamp bail attachment: The hook provides the connection between the mast hardware and a suitable drop wire clamp.
  • Galvanized steel construction: Hot-dip galvanizing helps protect the steel components against corrosion during outdoor service.
  • Multiple-drop planning: You can review several drop connections on one hook, with the final arrangement confirmed for space, engagement and loading.

Applications and Compatibility Checks

Choose this mast strap for overhead drop installations that require a clamp attachment on a compatible steel mast. It can support your planning for new service routes, additional drop connections or replacement of matching mast hardware.

Before selecting a cable clamp, check its cable range and construction requirements separately. Then compare the bail shape with the mast strap hook and confirm the direction of pull. The strap’s mast range does not describe the cable diameter.

If you are comparing mounting options, review the CW-MB drop wire mast bracket. Its listed mast range and galvanizing process differ from the CW-MS, so check the complete specification before choosing an alternative.

How to Select and Use Your Mast Strap

  1. Identify the mast: Record the pipe designation, actual outside diameter and mounting location. Confirm the fit within the listed 1¼–2 inch range using the supply drawing.
  2. Plan the drop layout: List the clamps, number of drops and directions of pull. Check the mast support and complete assembly against your required loads.
  3. Inspect the supplied parts: Check the strap, bolts, nuts and washers against your order. Inspect the hook and galvanized surfaces for damage.
  4. Position the strap: Place it around the steel mast in the orientation shown on the approved drawing. Align the hook with the intended connections.
  5. Secure the mounting: Install the specified fasteners and follow their tightening requirements. Check seating and alignment before attaching the drop hardware.
  6. Connect and verify: Fit compatible clamp bails as instructed. Confirm engagement, cable routing and clearance between drops before the assembly enters service.

Use the approved assembly drawing and component instructions for final installation details. The available product information does not specify a tightening torque or rated load.

Own-Factory Production and Quality Control

Hbcrownwealth operates its own factory in China. You can coordinate your mast dimensions, connection requirements and production schedule directly with our team. Efficient manufacturing and strict quality control support consistent supply for your overhead hardware orders.

The parameter table lists AISI 1008 for the strap, while the supplied hardware is described as Grade 2 steel. Confirm the applicable material and fastener requirements in the order specification. Also provide any coating inspection or testing criteria so we can confirm the available documentation and scope.

OEM/ODM Support and Shipment Planning

You can request an OEM/ODM review by sending your drawings and proposed changes. Our team confirms feasibility and quotation details before you approve production.

In addition, we coordinate manufacturing and logistics to support prompt dispatch. Share your quantity, destination and required delivery date early. You can then agree on a shipment plan alongside the associated drop wire clamps and installation materials.

Frequently Asked Questions

What mast size does the CW-MS fit?

The listed mast range is 1¼–2 inches. Provide the actual outside diameter and pipe designation so Hbcrownwealth can confirm the correct fit.

Does the mast strap hold the cable directly?

No. Its hook accepts the bail of a compatible drop wire clamp. Choose the clamp according to your cable and application requirements.

What hardware is included?

The stated supply includes bolts, nuts and washers. Confirm the sizes and quantities in the quotation before ordering.

How many drops can the hook accept?

The product supports multiple drops, but no fixed maximum count is stated. Send your clamp details and load requirements for review of the complete arrangement.

What do you need for a wholesale quotation?

Send the CW-MS model, quantity, mast dimensions and destination. Include the clamp bail details, intended drop layout and any material, inspection or OEM/ODM requirements.

Your Mast Strap Manufacturer and Wholesaler in China

Hbcrownwealth is a professional mast strap manufacturer, supplier and wholesaler in China. You can source the CW-MS alongside other mast and pole mounting hardware for your overhead cable projects.

Request your CW-MS mast strap quotation with your mounting and clamp details. Our team will help you confirm the product specification, supply scope and delivery arrangements.
